T105 Rubber Rebound Tester Operation
2024/01/25
T105 Rubber Rebound Tester is used for testing the resilience of vulcanized rubber.During the test,move the iron rod so that the end of the iron rod is at the position of 100 on the scale,and then let the iron rod fall freely.Read the average height of rebound during the fourth,fifth,and sixth strikes.
Compliant with standards:
ISO 4662,GB/T 1681,ASTM D 1054,DIN 53512,DIN 53573,JIS K6255
![](/en/uploadfile/2024/0125/20240125045805975.jpg)
![](/en/uploadfile/2024/0125/20240125045805975.jpg)
Operation:
1.Firstly,prepare the accessories and test samples;
2.Use 4 suspension wires to hang the impact head at a distance of 2000mm;
3.Install the prepared test samples in the fixture;
4.Tighten and secure;
5.Move the iron rod to the position of 100 on the scale;
6.Then allow the iron rod to fall freely;
7.Read the average height of rebound during the fourth,fifth,and sixth strikes;
8.is the rebound rate of the test material;
9.After the test is completed,remove the sample and record the interval scale value based on the horizontal rebound distance of the sample.Use a transformation calculation formula to calculate the rebound elasticity.
