QS-C1009B IUL Leather Rubbing Tester

QS-C1009B IUL leather rubbing color fastness tester



1 ﹑Use: QS-C1009B IUL leather rubbing color fastness tester is suitable for dyeing leather or textile materials after the friction of the damage and the degree of decolorization test.



2、Principle: QS-C1009B IUL leather rubbing color fastness tester is to dry or moist wool felt placed on the surface of the friction mallet, after a certain stroke and speed of reciprocal rubbing the test piece clamped on the friction table a certain number of times, to assess the degree of damage and decolorization.

3 ﹑ Standard: IULTCS leather rubbing color fastness tester according to QB / T 2537 and ISO11640 and other standard requirements for manufacturing.



4, IULTCS leather friction tester technical parameters.



Standard: ISO11640, EN344. test piece: 120mm × 20mm.

Wool cloth area: 15mm × 15mm.

Friction hammer weight: 500g. Weight: 500g.

Friction speed: 40±2r/min.

Friction distance: 35mm.

Counter control. 1~999999 can be set arbitrarily and stop automatically.

Power supply: 220V/50Hz, 3A.

Machine weight: 25Kg.

Machine shape: 490mm×340mm×550mm.



If you are interested in QS-C1009B IUL leather friction tester, want to know more detailed information about the price of the instrument, please send us a message!
